• Ultra fast 0.08 second transit time with 166 oz-in of torque at 6.0V
• Precise digital control
• Coreless motor for extended motor life and provides smoother operation
• Dual ball bearings provide less resistance for higher performance and longer life
• Z connectors are compatible with JR® and Spektrum™ receivers
• 8-inch 22 gauge wire
• Titanium gears for maximum durability and reliability
• Overload protection
• Mounting lug height optimized for surface applications

PRODUCT SPECIFICATIONS

Size Category:

Standard

Type:

Digital

Application:

1/10-scale servo for monster trucks, buggies and truggies

Torque:

133 oz-in (9.6 kg-cm) @ 4.8V; 167 oz-in (12 kg-cm) @ 6.0V

Speed:

0.10 sec/60° @ 4.8V; 0.08 sec/60° @ 6.0V

Length:

1.6 in (40mm)

Width:

0.8 in (20mm)

Height:

1.4 in (37mm)

Weight:

1.8 oz (52.4 g)

Bushing Or Bearing:

Bearing

Bearing:

Dual

Motor Type:

Coreless

Connector Type:

Z-connector

Gear Type:

Metal

Gear Material:

Titanium

Voltage:

4.8V or 6.0V (4- or 5-cell)
